Application
Suitable for daily street use and junior track use.
Compatible for Ford F-250, F-350 Truck Super Duty 6.0L Engine 2005-2007
OE/Part number
743250-5013, 7432505013S, 743250-5013S,
743250-0014，743250-5014, 743250-5014S，
743250-0004, 743250-5004S，7432509004, 743250-9004,
743250-0002, 743250-5002S，743250-0001，
743250-0005, 743250-5005，743250-9005,
743250-0016，743250-5016，743250-9016
743250-0021，743250-5021，743250-9021，
170025-0109,
1877831C93, 1879413C94；1879413C92，1879413C93，1877832C93,
1877832C91, 1877832C92, 1832255C91, 1832255C92,
1877834C91,1876493C91,1877831C91,1877834C91,1879413C91,
1854480C91,1854480C91,1845178C98,
1845178C95,1854593C91,1854593C92,1854593C94,
1832159C91, 1843761C93, 1843761C94,
1845322C91, 1846765C91, 1846767C91, 1882379C2,
1858116C91,1882380C1,
100211R,
5010147R93, 5010399R91, 5010422R91,
4C3Z6K682CB, 4C3Z6K682CBRM，4C3Z6K682CCRM,
5C3Z6K682AA, 5C3Z6K682A, 5C3Z6K682DA, 5C3Z6K682CA ,
5C3Z6K682CCRM, 5C3Z6K682CARM
Specification
Turbo Model: For GT3782VA
Engine: Power stroke
Displacement: 6.0L, 6000 compatible for ccm, V8
Cooling Type：Oil Cooled
Bearing Type: Floating Bearing
Condition: New
Accessories: You will receive the parts exactly as shown in the picture above
Package Size: 37x 34 x 33 cm
Package Weight: 19900g
Feature
Product Material
1\. Turbine housing: Silicon-Molybdenum - temperature resistant up to 850℃
2\. Steel Turbine Wheel: K419 alloy - high oxidation stability and resistance
up to 1000℃
3\. Compressor housing: ZL104 aluminium with lightweight
4\. Compressor wheel/blades: Aluminum blades-precision machining forging and
lightweight design
Product Performance
1\. OEM fitment turbo with upgraded material and performance
2\. Excellent high-temperature resistance, high efficiency and durability
3\. Rich experience in turbo production and own factory
4\. High-Speed oil seal ring and Precision clearance
Product Certification: TÜV ISO 9001 CERTIFIED
Technology Advantage:
1\. 100% balancing Test by TURBO TECHNICS VSR3
2\. G3-min-Flow VNT Turbo testing
3\. Advanced Actuator Tester/Programmer
Note
Please confirm your original turbo PART NUMBER before Purchasing.
Professional installation is highly recommended.
Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
